Model No. 27129001
Offering our customers the highest quality at all times is a fundamental part of the Hansgrohe company philosophy.
Please always observe the safety and installation information for your product. You will find these details within the assembly instructions.
| Item No. | DescriptionModel No. |
|---|
| b | tile-matching-disk 7 mm98681000 |
| a | cover cap95433000 |
| c | pushbutton92848000 |
| d | connecting thread92861000 |
| 1 | shower arm98493000 |
| 2 | O-ring 17x2,598387000 |
| 3 | hollow set screw M6x598447000 |
| 4 | screw92137000 |
| 5 | O-ring 20x298165000 |
| 6 | escutcheon Ø 80 mm95690000 |
| 7 | mounting set98716000 |
| 8 | O-ring 72x298395000 |
| 9 | wall flange95687000 |
| 10 | selector assy98343000 |
| 11 | cover98344000 |
| 12 | O-ring 3x198384000 |
| 13 | filter97735000 |
| 14 | hollow set screw M4x1097667000 |
| 15 | O-ring 17x298199000 |
| 16 | pipe 930 mm / Ø 25 mm98496000 |
| 17 | support, assy95480000 |
| 18 | hollow set screw M5x1097672000 |
| 19 | escutcheon98340000 |
| 20 | isolation valve98341000 |
| 21 | filter packing96922000 |
| 22 | set of nuts96157000 |
| 23 | non return valve96737000 |
| 24 | O-ring 12x2,2598382000 |
| 25 | handle95836001 |
| 26 | handle fixing set95843000 |
| 27 | O-ring 26x1,598390000 |
| 28 | stop ring for flow control95927000 |
| 29 | nut98913000 |
| 30 | safety set for temperature control95839001 |
| 31 | shut off unit with selector98283000 |
| 32 | O-ring 14x298129000 |
| 33 | shower hose 1,60 m28276003 |
| 34 | filter packing94246000 |
| 35 | handshower26531001 |
| 36 | showerhead cpl.98376001 |
| 37 | thermostat cartridge98282000 |
| 38 | spray body92291000 |
| 39 | seal98058000 |
| 40 | sleeve92166000 |
